6.5HP Engine Surface Concrete Vibrator | Plate Compactor for Ground Compaction Soil Dirt Vibratory

$500.00 USD

Sale Sold out

If you would like to purchase this Concrete Vibrating Plate, you can contact us. We offer it at wholesale cost. Customized delivery according to your requirements

1. The self-propelled plate compactor has a 6.5HP engine, delivering 12 inch compaction depth of 3200 lbs of compaction force and 5,500 vibrations per minute;
2. Function: Raising the density of loose dirt, soil, gravel, sand, asphalt and other media to form a strong & level foundation.
3. Speed up the throttle, the 21-5/8" x 14-1/2" one-piece stamped plate can travel 72 ft/min
4. The flat concrete vibrator has a specially designed shock absorption system, improves operator comfort and reduces fatigue. Also, the folding transport wheels kit makes it easy to move around your workplace and store it.
5. Working efficiency up to 5000 ft²/h

High quality plate compactor is suitable for compacting the edges of road, abutment channel, groove in narrow trenches. The designing of square-shaped base and handle is more helpful and comfortable for the operators to changing working directions.

Open plate provides self cleaning.

1. Radius base plate for easy access to corners.

2. Sealed belt cover to prevent sand and oil entrance.

3. Heavy-duty shock mounts reduce vibration to the upper engine and handle.

4. Foldable handle easy for transportation and storage,travelling wheel for easy transportation.

Model	C60	C80T
Engine type	Air-cooled,single cylinder,4-strock EPA CE	Air-cooled,single cylinder,4-strock EPA CE
Drive Mode	Electric / Diesel / Gasoline	Electric / Diesel / Gasoline
Power		6.5HP
Base Plate Size	550 x 370 mm	600 x 450 mm
Max. Compaction Force	3200 LB (14KN)	4100 lbs (18KN)
Vibration Frequency	5000 VPM	5000 VPM
Compaction Depth	300mm	300mm
Max Travel Speed	72 ft/min	66 ft/min
Gradeability	< 20°	< 20°
